Overview

HPE J9421A is a HP MSM760 Access Controller.

Quick Spec

Figure 1 shows the appearance of HPE J9421A.

Table 1 shows the quick spec.

Product Code	J9421A
Type	HP MSM760 Access Controller
Pts	· 2 RJ-45 autosensing 10/100/1000 pts (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half full; 1000BASE-T: full only · 1 RJ-45 serial console pt
Suppted	· IEEE 802.11 n/a/b/g access points and/ access devices · 40 to 200 access points and/ access devices (in increments of 10 40)
Dimensions (W x D x H)	43.99 x 39.07 x 4.45 cm (17.32 x 15.38 x 1.75 in) (1U height)
Weight	6.1 kg (13.45 lb)

Product Details

Figure 2 shows the front panel of HPE J9421A.

HPE J9421A Front Panel

Note:

①	Power, Fault, and Locat LEDs
②	Console pt
③	LCD display
④	Keypad (not used)
⑤	USB pt (not used)
⑥	Ethernet Pts: 1=Internet, 2=LAN

Figure 3 shows the back panel of HPE J9421A.

Compare to Similar Items

Table 2 shows the comparison.

Product Code	J9420A	J9421A
Type	HP MSM760 Premium Mobility Controller	HP MSM760 Access Controller
Pts	· 2 RJ-45 autosensing 10/100/1000 pts (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half full; 1000BASE-T: full only · 1 RJ-45 serial console pt	· 2 RJ-45 autosensing 10/100/1000 pts (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half full; 1000BASE-T: full only · 1 RJ-45 serial console pt
Suppted	· IEEE 802.11 n/a/b/g access points and/ access devices · 40 to 200 access points and/ access devices (in increments of 10 40)	· IEEE 802.11 n/a/b/g access points and/ access devices · 40 to 200 access points and/ access devices (in increments of 10 40)

Get Me Infmation

Do you have any question about the J9421A?

Specification

J9421A Specifications
Type	HP MSM760 Access Controller
Ports	· 2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only · 1 RJ-45 serial console port
Dimensions (W x D x H)	43.99 x 39.07 x 4.45 cm (17.32 x 15.38 x 1.75 in) (1U height)
Weight	6.1 kg (13.45 lb)
Mounting and enclosure	Mounts in an EIA-standard 19-inch telco rack or equipment cabinet (hardware included); horizontal surface mounting only
Operating temperature	5° to 40°C (41° to 104°F)
Operating relative humidity	15% to 80%, noncondensing
Nonoperating/Storage temperature	-40° to 65°C (-40° to 149°F)
Nonoperating/Storage relative humidity	15% to 80%, noncondensing
Frequency	50/60 Hz
Maximum heat dissipation	457.87 kJ/hr (434 BTU/hr)
AC voltage	100 - 240 V ac
Current	2/1 A
Maximum power rating	127 W
Safety	UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1
Emissions	FCC part 15 Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003
Features	Supported: Supported IEEE 802.11 n/a/b/g access points and/or access devices 40 to 200 access points and/or access devices (in increments of 10 or 40) MSM firmware releases prior to MSM v5.7: 1,000 simultaneous guest access users upgradable in increments of 250 per 40-AP license pack, up to a maximum of 2,000 guest access users unlimited simultaneous users MSM v5.7 and later: 2,000 simultaneous guest access users with base product Included services: Plug-and-play AP management and WLAN management Guest access Captive portal PCI DSS compliance for wireless PoS traffic Support for Real-Time Location Services (RTLS) Standard Layer 2 roaming with VoWLAN support Support for up to 16 VSC profiles Unified policy enforcement and network visibility
